Insulation R-values required in IECC climate zone 5 — attic, walls, and floor
What the 2021 IECC requires in climate zone 5: insulation for the attic, walls, and floor. A thicker layer means a higher R-value.
What this diagram shows
A house cross-section showing the 2021 IECC minimum insulation R-values for climate zone 5 (cool): the required R-value for the attic or ceiling, the exterior walls, and the floor, with each layer drawn thicker where a higher R-value is required. Climate zone 5 covers Pennsylvania, New York, Michigan, the upper Midwest, and the interior Northwest. Values are from IECC Table R402.1.3.
